GENERAL SPESIFICATION AND USAGE AREAS
Switch mode rectifiers are the latest point of rectifier technology today. It helps to obtain excellent results in coating processes with its features such as being smaller in size, much higher operating efficiency, and low ripple ratio when compared to Classic Transformer Rectifier models. IGBT control with high frequency switching technique is used in Switch Mode Rectifier models. Because it does not contain an iron core transformer. They are manufactured in very small size and light weight. Thanks to its special technology, up to 30% net energy savings compared to thyristor controlled rectifiers at the same current and voltage values
it has not been proven. Wrong rectifier selections, wrong usage etc. in practical applications. When the circumstances are taken into account, it can be observed that savings of up to 40% are achieved.
TEKNİK ÖZELLİKLER (TECHNICAL SPECIFICATION) | |
Giriş Faz Sayısı (Input Phase Numb"er) | 1-3Faz |
Giriş Voltajı (Input Voltage) | 220-380 Volt (220-380 Volt) |
Çıkış Voltajı (Output Voltage) | 5-25 Volt |
Çıkış Akımı (Output Current ) | 10-15.000 Amper |
| Çıkış Dalgalanması (Output Ripple) | <%2 |
Soğutma (Cooling) | Hava-Su (Air-Water) |
Verim (Efficienc) | %90 |
Çalışma Sıcaklığı (Running Heat) | -20/50 ®C |
Programlı Çalışma (Programmed Running) | Her proses için özel çalışma programı Specific programs for every process |
Uzaktan Kumanda (Remote Control) | Harici operatör paneli RS485 haberleşmeli Communucative with RS485 external operator panel |
Timer (Timer) | İstenilen sürede çalışmayı sağlayan zamanlayıcı Timer for running at the given-desired-intended hours |
Amper Saat Metre (Ampere Clock Meter) | Amper/saat- Amper/dakika (Ampere/hour – Ampere /minute) |
Isı Koruma (Heat Shield) | IGBT ve diyot grupları üzerinde ısı sensörleri Heat sensor on diodes and IGBT groups |
Ölçüm (Measurement) | DC akım/gerilim ölçümü DC current/voltage measurement |
LCD Ekran (LCD Display) | 4x16 karakter, numerik tuş takımı 4x16 characters numeric key set |
Otomasyon (Automation) | Modbus, Profinet, Profibus, RS485 |
